Aluminium Powder (Al Powder)

Product Information

Aluminium is a chemical element with the symbol Al and atomic number 13. Aluminium has a density lower than those of other common metals; about one-third that of steel. It has a great affinity towards oxygen, forming a protective layer of oxide on the surface when exposed to air. Aluminium visually resembles silver, both in its color and in its great ability to reflect light. It is soft, nonmagnetic and ductile. It has one stable isotope: 27Al, which is highly abundant, making aluminium the twelfth-most common element in the universe. The radioactivity of 26Al is used in radiometric dating.

ATT specializes in producing high purity Aluminum Powder with the smallest possible average grain sizes for use in preparation of pressed and bonded sputtering targets and in Chemical Vapor Deposition (CVD) and Physical Vapor Deposition (PVD) processes including Thermal and Electron Beam (E-Beam) Evaporation, Low Temperature Organic Evaporation, Atomic Layer Deposition (ALD), Metallic-Organic and Chemical Vapor Deposition (MOCVD). Powders are also useful in any application where high surface areas are desired such as water treatment and in fuel cell and solar applications. Nanoparticles also produce very high surface areas. Our standard powder particle sizes average in the range of - 325 mesh, - 100 mesh, 10-50 microns and submicron (< 1 micron).

Synonyms

Aluminum particles, Aluminum microparticles, Aluminum micropowder, Aluminum micro powder, Aluminum micron powder, Aluminum submicron powder, Aluminum sub-micron powder, 11010, 653608, 202584, 11009, 266515, 1.01056, 10576, 11067

Aluminium Powder Specification

Size：Our standard powder particle sizes average in the range of - 325 mesh, - 100 mesh, 10-50 microns and submicron (< 1 micron).

Per your request or drawing

We can customized as required

Properties (Theoretical)

Molecular Weight	26.98
Appearance	Silvery
Melting Point	660.37 °C
Boiling Point	2467 °C
Density	2700 kg/m3
Solubility in H2O	N/A
Electrical Resistivity	2.6548 microhm-cm @ 0 °C
Electronegativity	1.5 Paulings
Heat of Fusion	2.55 Cal/gm mole
Heat of Vaporization	67.9 K-Cal/gm at om at 765 °C
Poisson's Ratio	0.35
Specific Heat	0.215 Cal/g/ K @ 25 °C
Tensile Strength	6800 psi Coldroled 16,000 psi.
Thermal Conductivity	2.37 W/cm/ K @ 298.2 K
Thermal Expansion	(25 °C) 23.1 µm·m-1·K-1
Vickers Hardness	167 MPa
Young's Modulus	70 GPa
Superconductivity critical temperature ( K )	1.1750
Temperature coefficient ( K⁻¹ )	0.00450 @0-100°C
Thermal emf against Pt (cold 0C - hot 100C) ( mV )	0.42

Applications of Aluminium Powder

• autoclave aerated concrete

• cosmetic colourant

• fingerprint powder[3]

• metallic paint

• pyrotechnics (including the M-80 firecracker)

• refractory

• rocket and missile fuel such as the solid rocket boosters of the Space Shuttle[4]

• thermite

Packing of Aluminium Powder

Standard Packing:

Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 440 gallon liquid totes Special package is available on request.

ATTs’ Aluminium Powder  is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.

Chemical Identifiers

Linear Formula	Al
CAS	7429-90-5
MDL Number	MFCD00134029
EC No.	231-072-3
Beilstein/Reaxys No.	N/A
Pubchem CID	5359268
IUPAC Name	aluminum
SMILES	[Al]
InchI Identifier	InChI=1S/Al
InchI Key	XAGFODPZIPBFFR-UHFFFAOYSA-N
