Product Code : EM-Er-5N-Cu
Erbium is one of the rare earth elements among Lanthanide series. Pure Erbium metal is malleable, soft, and fairly stable in air. Erbium ions fluoresce pink light are used in imaging and optical applications. Erbium oxidizes slower than some other rare-earth metals and has a high electrical resistivity. It is typically found in small quantities and in combination with other rare earths. As a pure metal, Erbium has limited applications, however it can be used as an alloying element with titanium.
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
| Product | Product Code | Purity | Size | Contact Us |
Product Information
Erbium is one of the rare earth elements among Lanthanide series. Pure Erbium metal is malleable, soft, and fairly stable in air. Erbium ions fluoresce pink light are used in imaging and optical applications. Erbium oxidizes slower than some other rare-earth metals and has a high electrical resistivity. It is typically found in small quantities and in combination with other rare earths. As a pure metal, Erbium has limited applications, however it can be used as an alloying element with titanium.
ATT provides high-quality Erbium Evaporation Materials for research and industry purposes at competitive prices. We can provide Erbium Evaporation Materials with different purity, size, and density according to your requirements.
Material Type: Erbium
Symbol: Er
Color/Appearance: Silvery White, Metallic
Synonyms
N/A
Copper Evaporation Materials Specification
Size：Pellet / Wire / Rod / Slug / Tablet / Customized
Per your request or drawing
We can customized as required
Properties（Theoretical）
| Molecular Weight | 382.56 |
| Appearance | Silvery |
| Melting Point | 1497 °C |
| Boiling Point | 2868 °C |
| Density | 9066kg/m ³ |
| Solubility in H2O | N/A |
| Electrical Resistivity | 107.0 microhm-cm @ 25 °C |
| Electronegativity | 1.2 Paulings |
| Heat of Fusion | 4.10 Cal/gm mole |
| Heat of Vaporization | 67 K-Cal/gm atom at 2863 °C |
| Poisson's Ratio | 0.237 |
| Specific Heat | 0.0401 Cal/g/K @ 25 °C |
| Tensile Strength | N/A |
| Thermal Conductivity | 0.145 W/cm/K @ 298.2 K |
| Thermal Expansion | (r.t.) (poly) 12.2 µm/(m·K) |
| Vickers Hardness | 589 MPa |
| Young's Modulus | 69.9 GPa |
Application of Erbium Evaporation Materials
• Used in deposition processes including semiconductor deposition, chemical vapor deposition (CVD) and physical vapor deposition (PVD)
• Used for optics including wear protection, decorative coatings, and displays.
Packing of Erbium Evaporation Materials
Standard Packing:
Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 440 gallon liquid totes Special package is available on request. They are vacuum sealed. The MSDS and Material Certification Sheets will be packed with the product.
ATTs’Erbium Evaporation Materials is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.
Chemical Identifiers
| Linear Formula | Er |
| MDL Number | MFCD00010987 |
| EC No. | 231-160-1 |
| Beilstein/Reaxys No. | N/A |
| Pubchem CID | 23980 |
| SMILES | [Er] |
| InchI Identifier | InChI=1S/Er |
| InchI Key | UYAHIZSMUZPPFV-UHFFFAOYSA-N |
