Gadolinium Evaporation Materials, Gd

Product Code : EM-Gd-5N-Cu

Gadolinium is a rare earth metal that is used as a vaporization material in a variety of applications, including optical fibers, medical imaging, and semiconductor manufacturing. When used in an evaporator, gadolinium is heated to high temperatures in order to create a vapor that deposits onto surfaces and forms films. Films created using gadolinium are typically very thin and are used to reduce the amount of light that passes through a particular material, to reflect light, or to block light altogether. Other uses of gadolinium include use as a catalyst, as an alloying element in steels, and as an absorber of neutrons in nuclear power plants.


Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.

Product Product Code Purity Size Contact Us
Gadolinium Evaporation Materials, Gd EM-Gd-2N-Cu 99% Customize
Gadolinium Evaporation Materials, Gd EM-Gd-3N-Cu 99.9% Customize
Gadolinium Evaporation Materials, Gd EM-Gd-4N-Cu 99.99% Customize
Gadolinium Evaporation Materials, Gd EM-Gd-5N-Cu 99.999% Customize

Product Information

Gadolinium is a rare earth metal that is used as a vaporization material in a variety of applications, including optical fibers, medical imaging, and semiconductor manufacturing. When used in an evaporator, gadolinium is heated to high temperatures in order to create a vapor that deposits onto surfaces and forms films. Films created using gadolinium are typically very thin and are used to reduce the amount of light that passes through a particular material, to reflect light, or to block light altogether. Other uses of gadolinium include use as a catalyst, as an alloying element in steels, and as an absorber of neutrons in nuclear power plants.

ATT provides high-quality Gadolinium  Evaporation Materials for research and industry purposes at competitive prices. We can provide Gadolinium  Evaporation Materials with different purity, size, and density according to your requirements.

Material Type:Gadolinium
Symbol:Gd
Color/Appearance:Silvery White, Metallic

CAS :

 7440-54-2


Synonyms

N/A


Gadolinium Evaporation Materials Specification

Size:Pellet / Wire / Rod / Slug / Tablet / Customized

Per your request or drawing

We can customized as required


Properties(Theoretical)

Molecular Weight157.25
AppearanceSilvery
Melting Point1312 °C
Boiling Point3250 °C
Density7901kg/m3
Solubility in H2ON/A
Electrical Resistivity140.5 microhm-cm @ 25 °C
Electronegativity1.1 Paulings
Heat of Fusion3.70 Cal/gm mole
Heat of Vaporization72 K-Cal/gm atom at 3266 °C
Poisson's Ratio0.259
Specific Heat0.055 Cal/g/K @ 25 °C
Tensile StrengthN/A
Thermal Conductivity0.105 W/cm/K @ 298.2 K
Thermal Expansion(100 °C, poly) 9.4 µm/(m·K)
Vickers Hardness570 MPa
Young's Modulus(? form) 54.8 GPa





Application of Gadolinium Evaporation Materials

• Used in deposition processes including semiconductor deposition, chemical vapor deposition (CVD) and physical vapor deposition (PVD)
• Used for optics including wear protection, decorative coatings, and displays.


Packing of Gadolinium Evaporation Materials

Standard Packing:

Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 440 gallon liquid totes Special package is available on request. They are vacuum sealed. The MSDS and Material Certification Sheets will be packed with the product.

ATTs’Gadolinium Evaporation Materials is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.




Chemical Identifiers

Linear FormulaGd
MDL NumberMFCD00011022
EC No.231-162-2
Beilstein/Reaxys No.N/A
Pubchem CID23982
SMILES[Gd]
InchI IdentifierInChI=1S/Gd
InchI KeyUIWYJDYFSGRHKR-UHFFFAOYSA-N
