Product Code : EM-GaS-5N-Cu
Gallium sulfide (GaS) is a semiconducting material used as an evaporation source for organic light emitting diodes, solar cell junctions, p-n junctions, and other electronic applications. The material has a melting point of 1420°C and is available in both crystalline and amorphous forms. GaS has high electrical conductivity and is easily deposited onto substrates, making it ideal for thin-film applications. It can also be used as a buffer layer between other films to create p-type and n-type layers in a semiconductor device. GaS can be evaporated using either thermal evaporation or electron-beam evaporation, both of which are frequently used methods in the semiconductor industry.
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
| Product | Product Code | Purity | Size | Contact Us |
Product Information
Gallium sulfide (GaS) is a semiconducting material used as an evaporation source for organic light emitting diodes, solar cell junctions, p-n junctions, and other electronic applications. The material has a melting point of 1420°C and is available in both crystalline and amorphous forms. GaS has high electrical conductivity and is easily deposited onto substrates, making it ideal for thin-film applications. It can also be used as a buffer layer between other films to create p-type and n-type layers in a semiconductor device. GaS can be evaporated using either thermal evaporation or electron-beam evaporation, both of which are frequently used methods in the semiconductor industry.
Material Type: Gallium sulfide
Symbol: GaS
Gallium Sulfide (GaS) Evaporation Material Specification
Size：Pellet / Wire / Rod / Slug / Tablet / Customized
Per your request or drawing
We can customized as required
Properties（Theoretical）
| Compound Formula | GaS |
| Molecular Weight | 101.79 |
| Appearance | Yellow crystals |
| Melting Point | 965 °C, 1238 K, 1769 °F |
| Boiling Point | N/A |
| Density | 3.86 g/cm3 |
| Solubility in H2O | N/A |
| Exact Mass | N/A |
| Monoisotopic Mass | N/A |
Application of Gallium Sulfide (GaS) Evaporation Material Evaporation Material
• Used in deposition processes including semiconductor deposition, chemical vapor deposition (CVD) and physical vapor deposition (PVD)
• Used for optics including wear protection, decorative coatings, and displays.
Packing of Gallium Sulfide (GaS) Evaporation Material Evaporation Material
Standard Packing:
Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 440 gallon liquid totes Special package is available on request. They are vacuum sealed. The MSDS and Material Certification Sheets will be packed with the product.
ATTs’Gallium Sulfide (GaS) Evaporation Material Evaporation Material is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.
Chemical Identifiers
| Linear Formula | GaS |
| MDL Number | N/A |
| EC No. | 234-688-0 |
| Beilstein/Reaxys No. | N/A |
| Pubchem CID | 25113419 |
| IUPAC Name | gallium sulfide |
| SMILES | [Ga+3].[Ga+3].[S-2].[S-2].[S-2] |
| InchI Identifier | InChI=1S/2Ga.3S/q2*+3;3*-2 |
| InchI Key | BVSHTEBQPBBCFT-UHFFFAOYSA-N |
