Product Code : AL-In600-NN-FA
Ni-72% Cr-14-17% Fe-6-10%.Inconel alloy is a family of nickel-chromium superalloys and a trademark of Special Metals Corporation. Inconel (Nickel-Chromium-Iron) Alloy 600 is a highly corrosion and heat resistant alloy with excellent mechanical properties ideal for use in high temperature applications such as heat-treating, aerospace, electronics components, and nuclear reactors. The Inconel 600 (Alloy 600, UNS N06600) Wire's strength and oxidation resistance at high temperatures thanks to its nickel and chromium content make it useful for many applications in the heat-treating industry.
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
| Product | Product Code | Purity | Size | Contact Us |
Product Information
Inconel alloy is a family of nickel-chromium superalloys and a trademark of Special Metals Corporation. Inconel (Nickel-Chromium-Iron) Alloy 600 is a highly corrosion and heat resistant alloy with excellent mechanical properties ideal for use in high temperature applications such as heat-treating, aerospace, electronics components, and nuclear reactors. The Inconel 600 (Alloy 600, UNS N06600) Wire's strength and oxidation resistance at high temperatures thanks to its nickel and chromium content make it useful for many applications in the heat-treating industry.Ni-72% Cr-14-17% Fe-6-10%.
Synonyms
Inconel 600 Alloy Flange Specification
Size：customized
Purity: customized
Per your request or drawing
We can customized as required
Properties（Theoretical）
| Appearance | Solid |
| Melting point ( C ) | 1359.00 - 1425.00 |
| Density | 8.47 g/cm3 |
| Electrical Resistivity | 1.03 µΩ·m |
| Specific Heat | 444 J/kg·°C |
| Thermal conductivity ( W m⁻¹ K⁻¹ ) | 14.80 @23°C |
| Tensile strength ( MPa ) | 600.00 - 1200.00 |
| Tensile Strength | 520-830 MPa (annealed) |
| Curie temperature ( C ) | -124 |
| Initial permeability | 1.01 |
| Elongation at break ( % ) | < 50.0 |
| Hardness - Brinell | 120 - 290 |
| Izod impact strength ( J m⁻¹ ) | 160 |
| Modulus of elasticity ( GPa ) | 157 |
| Shear strength ( MPa ) | 420 - 570 |
| Coefficient of thermal expansion ( x10⁻⁶ K⁻¹ ) | 11.500 - 13.300 @20-100°C |
Chemical Composition, %
| Cr | Fe | Ni | Cu | Mg | S | Si | C | |
| Max | 17 | 10 | 0.5 | 1 | 0.015 | 0.5 | 0.15 | |
| Min | 14 | 6 | 72 |
We can customized as required
Applications of Inconel 600 Alloy Flange
Superheaters
Jet engines
Electronic parts
Steam generators
Chemical processing
Food processing
Inconel is often encountered in extreme environments. It is common in gas turbine blades, seals, and combustors, as well as turbocharger rotors and seals, electric submersible well pump motor shafts, high temperature fasteners, chemical processing and pressure vessels, heat exchanger tubing, steam generators and core components in nuclear pressurized water reactors
Packing of Inconel 600 Alloy Flange
Standard Packing:
Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 440 gallon liquid totes Special package is available on request.
ATTs’ Inconel 600 Alloy Flange is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.
Inconel Alloys Include
· Inconel 188: Readily fabricated for commercial gas turbine and aerospace applications.
· Inconel 230: Alloy 230 Plate & Sheet mainly used by the power, aerospace, chemical processing and industrial heating industries.
· Inconel 600: Solid solution strengthened
· Inconel 601:
· Inconel 617: Solid solution strengthened (nickel-chromium-cobalt-molybdenum), high-temperature strength, corrosion and oxidation resistant, high workability and weldability. Incorporated in ASME Boiler and Pressure Vessel Code for high temperature nuclear applications such as molten salt reactors
· Inconel 625: Acid resistant, good weldability. The LCF version is typically used in bellows.
· Inconel 690: Low cobalt content for nuclear applications, and low resistivity
· Inconel 713C: Precipitation hardenable nickel-chromium base cast alloy
· Inconel 718: Gamma double prime strengthened with good weldability
· Inconel X-750: Commonly used for gas turbine components, including blades, seals and rotors.
· Inconel 751: Increased aluminium content for improved rupture strength in the 1600 °F range
· Inconel 792: Increased aluminium content for improved high temperature corrosion resistant properties, used especially in gas turbines
· Inconel 907
· Inconel 909
· Inconel 706
· Inconel 939: Gamma prime strengthened to increase weldability.
· Inconel 925: Inconel 925 is a nonstabilized austenitic stainless steel with low carbon content.
In age hardening or precipitation strengthening varieties, alloying additions of aluminum and titanium combine with nickel to form the intermetallic compound Ni3(Ti,Al) or gamma prime (γ′). Gamma prime forms small cubic crystals that inhibit slip and creep effectively at elevated temperatures.
| Inconel | Element, proportion by mass (%) | ||||||||||||||
| Ni | Cr | Fe | Mo | Nb & Ta | Co | Mn | Cu | Al | Ti | Si | C | S | P | B | |
| 600 | ≥72.0 | 14.0–17.0 | 6.0–10.0 | — | ≤1.0 | ≤0.5 | ≤0.5 | ≤0.15 | ≤0.015 | ||||||
| 617 | 44.2–61.0 | 20.0–24.0 | ≤3.0 | 8.0–10.0 | 10.0–15.0 | ≤0.5 | ≤0.5 | 0.8–1.5 | ≤0.6 | ≤0.5 | 0.05–0.15 | ≤0.015 | ≤0.015 | ≤0.006 | |
| 625 | ≥58.0 | 20.0–23.0 | ≤5.0 | 8.0–10.0 | 3.15–4.15 | ≤1.0 | ≤0.5 | ≤0.4 | ≤0.4 | ≤0.5 | ≤0.1 | ≤0.015 | ≤0.015 | ||
| 690 | ≥58 | 27–31 | 7–11 | ≤0.50 | ≤0.50 | ≤0.50 | ≤0.05 | ≤0.015 | |||||||
| Nuclear grade 690 | ≥58 | 28–31 | 7–11 | ≤0.10 | ≤0.50 | ≤0.50 | ≤0.50 | ≤0.04 | ≤0.015 | ||||||
| 718 | 50.0–55.0 | 17.0–21.0 | Balance | 2.8–3.3 | 4.75–5.5 | ≤1.0 | ≤0.35 | ≤0.3 | 0.2–0.8 | 0.65–1.15 | ≤0.35 | ≤0.08 | ≤0.015 | ≤0.015 | ≤0.006 |
| X-750 | ≥70.0 | 14.0–17.0 | 5.0–9.0 | 0.7–1.2 | ≤1.0 | ≤1.0 | ≤0.5 | 0.4–1.0 | 2.25–2.75 | ≤0.5 | ≤0.08 | ≤0.01 |
