Product Code : RE-GdF3-5N-PO
Gadolinium Fluoride (GdF3), also known as Gadolinium Trifluoride, Trifluorogadolinium, and Gadolinium (III) Fluoride, is one of the essential Gadolinium compounds. It is insoluble in water.
Gadolinium Fluoride is used for making optical glass and dopant for Gadolinium Yttrium Garnets, which have microwave applications. Gadolinium is used for making Gadolinium Yttrium Garnet. It has microwave applications and is used to fabricate various optical components and as a substrate material for magneto-optical films. It is also used to make Gadolinium Yttrium Garnet (Gd:Y3Al5O12). Gadolinium Gallium Garnet (GGG, Gd3Ga5O12) is used for imitation diamonds and computer bubble memory. It can also serve as an electrolyte in Solid Oxide Fuel Cells (SOFCs).
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
Product | Product Code | Purity | Size | Contact Us |
Product Information
Gadolinium Fluoride (GdF3), also known as Gadolinium Trifluoride, Trifluorogadolinium, and Gadolinium (III) Fluoride, is one of the essential Gadolinium compounds. It is insoluble in water.
Gadolinium Fluoride is used for making optical glass and dopant for Gadolinium Yttrium Garnets, which have microwave applications. Gadolinium is used for making Gadolinium Yttrium Garnet. It has microwave applications and is used to fabricate various optical components and as a substrate material for magneto-optical films. It is also used to make Gadolinium Yttrium Garnet (Gd:Y3Al5O12). Gadolinium Gallium Garnet (GGG, Gd3Ga5O12) is used for imitation diamonds and computer bubble memory. It can also serve as an electrolyte in Solid Oxide Fuel Cells (SOFCs).
Gadolinium Fluoride Synonyms
Gadolinium trifluoride, Trifluorogadolinium, Gadolinium(III) fluoride, GadoliniumFluorid, Fluorure De Gadolinium, Fluoruro Del Gadolinio
Gadolinium Fluoride (GdF3) Powder Specification
Per your request or drawing
We can customized as required
Properties(Theoretical)
Compound Formula | F3Gd |
Molecular Weight | 214.25 |
Appearance | powder |
Melting Point | 1231 °C (2248 °F) |
Boiling Point | N/A |
Density | 7.1 g/cm3 |
Solubility in H2O | N/A |
Exact Mass | N/A |
Monoisotopic Mass | 214.91931 Da |
Grade | 99.999% | 99.99% | 99.9% | 99% |
CHEMICAL COMPOSITION | ||||
Gd2O3 /TREO (% min.) | 99.999 | 99.99 | 99.9 | 99 |
TREO (% min.) | 81 | 81 | 81 | 81 |
Rare Earth Impurities | ppm max. | ppm max. | % max. | % max. |
La2O3/TREO CeO2/TREO Pr6O11/TREO Nd2O3/TREO Sm2O3/TREO Eu2O3/TREO Tb4O7/TREO Dy2O3/TREO Ho2O3/TREO Er2O3/TREO Tm2O3/TREO Yb2O3/TREO Lu2O3/TREO Y2O3/TREO | 1 1 1 1 5 5 5 1 1 5 1 1 1 5 | 5 10 10 10 30 30 20 5 5 5 5 5 5 5 | 0.005 0.005 0.005 0.005 0.02 0.05 0.01 0.01 0.005 0.005 0.001 0.001 0.001 0.03 | 0.01 0.01 0.01 0.01 0.1 0.1 0.05 0.05 0.05 0.01 0.01 0.01 0.01 0.05 |
Non-Rare Earth Impurities | ppm max. | ppm max. | % max. | % max. |
Fe2O3 SiO2 CaO CuO PbO NiO Cl- | 3 50 50 3 3 3 150 | 5 50 50 5 5 10 200 | 0.003 0.015 0.05 0.001 0.001 0.001 0.6 | 0.005 0.03 0.06 0.003 0.003 0.005 1 |
Gadolinium Fluoride (GdF3) Powder Applications
Used in magnetic resonance imaging (MRI)
Used in the production of high-energy lasers
Used as a polishing agent for semiconductors
Packing of Gadolinium Fluoride (GdF3) Powder
Standard Packing:
Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 440 gallon liquid totes Special package is available on request.
ATTs’Gadolinium Fluoride (GdF3) Powder is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.
Chemical Identifiers
Linear Formula | GdF3 |
CAS | 13765-26-9 |
MDL Number | MFCD00016113 |
EC No. | 237-369-4 |
Beilstein/Reaxys No. | N/A |
Pubchem CID | 83716 |
IUPAC Name | Trifluorogadolinium |
SMILES | F[Gd](F)F |
InchI Identifier | InChI=1S/3FH.Gd/h3*1H;/q;;;+3/p-3 |
InchI Key | TYIZUJNEZNBXRS-UHFFFAOYSA-K |
