Magnesium Zirconium Master Alloy (Mg-Zr Alloy)

Product Code : AL-MgZr-5N-CU

Magnesium-zirconium (MgZr) master alloy is also called Magnesium zirconium casting alloy. Magnesium alloys usually need to add some alloying elements to improve their performance. Zirconium can easily become crystal nuclei during crystallization, which obviously refines the alloy grains, thereby greatly improving the mechanical properties of magnesium alloys. In addition, Zr also has a greater effect on improving the corrosion resistance and heat resistance of magnesium alloys.

agnesium-zirconium is one of numerous metallic alloys manufactured by ATT. Available alloy forms include sheets and plates, discs, foils, rods, tubes, powders, and other shapes. ATT can produce magnesium-zirconium in various standard ratios of Mg:Zr; custom alloy compositions are also available. Advanced chemical analysis is available for all alloy products by best demonstrated techniques including X-ray fluorescence (XRF), glow discharge mass spectrometry (GDMS), and inert gas fusion. Please request a quote above to receive pricing information based on your specifications for alloy composition and form.

Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.

Product Product Code Purity Size Contact Us
Magnesium Zirconium Master AlloyAL-MgZr-2N-CU99%Customized
Magnesium Zirconium Master AlloyAL-MgZr-3N-CU99.9%Customized
Magnesium Zirconium Master AlloyAL-MgZr-3N5-CU99.95%Customized
Magnesium Zirconium Master AlloyAL-MgZr-4N-CU99.99%Customized
Magnesium Zirconium Master AlloyAL-MgZr-5N-CU99.999%Customized

Product Information

Magnesium-zirconium (MgZr) master alloy is also called Magnesium zirconium casting alloy. Magnesium alloys usually need to add some alloying elements to improve their performance. Zirconium can easily become crystal nuclei during crystallization, which obviously refines the alloy grains, thereby greatly improving the mechanical properties of magnesium alloys. In addition, Zr also has a greater effect on improving the corrosion resistance and heat resistance of magnesium alloys.

agnesium-zirconium is one of numerous metallic alloys manufactured by ATT. Available alloy forms include sheets and plates, discs, foils, rods, tubes, powders, and other shapes. ATT can produce magnesium-zirconium in various standard ratios of Mg:Zr; custom alloy compositions are also available. Advanced chemical analysis is available for all alloy products by best demonstrated techniques including X-ray fluorescence (XRF), glow discharge mass spectrometry (GDMS), and inert gas fusion. Please request a quote above to receive pricing information based on your specifications for alloy composition and form.


Synonyms

MgZr, Mg- 33.3Zr master alloy, Zirmax, Microzir, ZrMg, Mg:Zr 70:30

Magnesium Zirconium Master Alloy Specification

Size:customized

Purity: 2N(99%), 3N(99.9%), 3N5(99.95%), 4N(99.99%), 5N(99.999%)

Per your request or drawing

We can customized as required


Properties (Theoretical)

Compound FormulaMgZr
Molecular Weight115.529
AppearanceGray metallic solid in various forms   such as sheets, discs, foils, rods, tubes, ingots
Melting Point650 °C (1200 °F)
Boiling PointN/A
Density1.8 g/cm3
Solubility in H2ON/A
Electrical Resistivity0.00000570 ohm-cm
Poisson's Ratio0.29
Specific Heat1040 J/kg-K
Tensile Strength180 MPa (Ultimate)/ 51 MPa (Yield)
Thermal Conductivity120 W/m-K
Thermal Expansion27 µm/m-K
Young's Modulus44 GPa
Monoisotopic Mass113.89 g/mol


Magnesium Metal Products

MaterialsMg
Plate
Sheet
Strip
Rod
Sputtering   Target
Tube

Other: Spherical Magnesium Powder, Magnesium crucibles, Magnesium nuts, Magnesium bolts, Magnesium heating elements, and Magnesium shielding screens.


Magnesium Zirconium Master Alloy Specification

ItemPurity(%)Content of Ca

AL-MgZr-3N-CU

99.925±2%

AL-MgZr-3N-CU

99.930±2%

AL-MgZr-NN-CU

99.9Customized

We can customized as required

Applications of Magnesium Zirconium Master Alloy

Used to refine the grain of magnesium alloy and improve the strength of magnesium alloy.The magnesium calcium alloy is primarily used in the removal of bismuth from lead for refinement purposes. The alkaline elements in the alloy react with the molten lead under controlled conditions.


Packing of Magnesium Zirconium Master Alloy

Standard Packing:

Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 440 gallon liquid totes Special package is available on request.

ATTs’ Magnesium Zirconium Master Alloy is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.


Chemical Identifiers

Linear FormulaMg-Zr
MDL NumberMFCD00214041
EC No.N/A
Pubchem CID72944029
IUPAC Namemagnesium; zirconium
SMILES[Mg].[Zr]
InchI IdentifierInChI=1S/Mg.Zr
InchI KeyQRNPTSGPQSOPQK-UHFFFAOYSA-N
