Molybdenum Boat(Mo Boat) Supply

Product Information

Molybdenum boat is also known as evaporated molybdenum boat or coated molybdenum boat, it is made of molybdenum sheet after high temperature stamping molding, can be used in 1400℃~1900℃ above the condition of a molybdenum base alloy. According to different processing methods, it is divided into different types including stamping boat, folding boat, welding boat and riveting boat.

It has good electrical and thermal conductivity, high temperature resistance, corrosion resistance and wear resistance, so it is mainly used in coating technology, electronics industry, power engineering and other fields, such as capacitor sintering, vacuum thermal evaporation, nuclear fuel sintering, thermocouple shell, etc.

Synonyms

Moly evaporation boats, moly coated boat, molybdenum trays

Specifications Of Molybdenum Boat

Size	10-300mm H x 15-500mm W x 30-1000mm L x 0.25-15mm WT
Material	Molybdenum
Technique	stamping, welding, riveting, folding
Purity	≥99.95%
Standard	ASTM B386

ATT can design and manufacture according to customer's requirements beyond the standard size.

Chemical Composition for Molybdenum Boat

Main component	Impurity content(≤)
MO	Al	Ca	Fe	Mg	Ni	Si	C	N	O
Remainder	0.002	0.002	0.01	0.002	0.005	0.01	0.01	0.003	0.008

Molybdenum Boat Properties

Molecular Weight	95.94
Appearance	Silvery
Melting Point	2623 °C
Boiling Point	4639 °C
Density	10280 kg/m³
Solubility in H2O	N/A
Electrical Resistivity	5.2 microhm-cm @ 0 °C
Electronegativity	1.9 Paulings
Heat of Fusion	6.6 Cal/gm mole
Heat of Vaporization	128 K-Cal/gm atom at 4612 °C
Poisson's Ratio	0.31
Specific Heat	0.0599 Cal/g/K @ 25 °C
Tensile Strength	N/A
Thermal Conductivity	1.38 W/cm/K @ 298.2 K
Thermal Expansion	(25 °C) 4.8 µm·m^-1·K^-1
Vickers Hardness	1530 MPa
Young's Modulus	329 GPa

Applications of Molybdenum Boat

*In the field of electronic products: LCD display, LCD TV, MP4, car display, mobile phone display, digital camera and applause computer, etc..

* In the field of coated glass: telescope lenses, eye lenses, all kinds of coated glass, etc..

* In the field of touch screen: screens of mobile phones, computers, MP4 and other digital products.

* In the field of information display: LCD screen, all kinds of LCD screen, plasma screen, etc..

*In the field of information storage: magnetic information storage, magneto-optical information storage, etc..

* In decorative ornaments: mobile phone case, watch case, glasses frame, hardware, trinkets and other coating.

Packaging of Molybdenum Boat

Standard Packing:

Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 440 gallon liquid totes Special package is available on request.

ATTs’Molybdenum Boat is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.

Chemical Identifiers

Linear Formula	Mo
CAS	7439-98-7
MDL Number	MFCD00003465
EC No.	231-107-2
Beilstein/Reaxys No.	N/A
Pubchem CID	23932
SMILES	[Mo]
InchI Identifier	InChI=1S/Mo
InchI Key	ZOKXTWBITQBERF-UHFFFAOYSA-N

Product	Product Code	Purity	Size	Contact Us
Molybdenum Boat	ME-Mo-99%-BO	99%	10-300mm H x 15-500mm W x 30-1000mm L x 0.25-15mm WT
Molybdenum Boat	ME-Mo-99.9%-BO	99.9%	10-300mm H x 15-500mm W x 30-1000mm L x 0.25-15mm WT
Molybdenum Boat	ME-Mo-99.95%-BO	99.95%	10-300mm H x 15-500mm W x 30-1000mm L x 0.25-15mm WT
