Molybdenum Crucible(Mo Crucible)

Product Code : ME-Mo-99.95%-CR

Molybdenum crucible is made of high purity molybdenum powder, and the operating temperature is between 1100℃ and 1700℃. According to the process of molybdenum crucible can be divided into machine crucible, sintering crucible, spinning crucible, stamping crucible. Because the melting point of molybdenum is as high as 2610℃, molybdenum crucible is widely used in sapphire single crystal growth furnace, quartz glass melting furnace, rare earth smelting furnace and other industrial furnace core vessels.

CAS #: 7439-98-7

Linear Formula: Mo

MDL Number: MFCD00003465

EC No.: 231-107-2

INQUIRY Next Products

Product Information

Synonyms

Moly

Specifications of Molybdenum Crucible

Size	10-500mm OD x 1-30mm WT x 10-600mm H, Customized
Material	Mo ≥ 99.95%
Standard	ASTM B387
Purity	≥99.95%
Technology	Sintering, Forging, Sintering and Machining

Dimensions of Molybdenum Crucible

Technology	Dimension(mm)
Technology	Diameter	Wall Thickness	High
Sintering	10-500	1-30	10-600
Forging	10-130	1-20	10-200
Sintering and Machining	100-450	1-30	10-500

ATT supply all kinds of Molybdenum crucible and other Molybdenum parts (including heaters, heat insulation screens, sheets and supports, etc.) used in the process of sapphire growth and rare-earth melting and we can manufacture the products according to customers’drawings and specific requirements.

Chemical Composition for Molybdenum Crucible

Main component	Impurity content(≤)
MO	Al	Ca	Fe	Mg	Ni	Si	C	N	O
Remainder	0.002	0.002	0.01	0.002	0.005	0.01	0.01	0.003	0.008

Molybdenum Crucible Properties

Molecular Weight	95.94
Appearance	Silvery
Melting Point	2623 °C
Boiling Point	4639 °C
Density	10280 kg/m³
Solubility in H2O	N/A
Electrical Resistivity	5.2 microhm-cm @ 0 °C
Electronegativity	1.9 Paulings
Heat of Fusion	6.6 Cal/gm mole
Heat of Vaporization	128 K-Cal/gm atom at 4612 °C
Poisson's Ratio	0.31
Specific Heat	0.0599 Cal/g/K @ 25 °C
Tensile Strength	N/A
Thermal Conductivity	1.38 W/cm/K @ 298.2 K
Thermal Expansion	(25 °C) 4.8 µm·m^-1·K^-1
Vickers Hardness	1530 MPa
Young's Modulus	329 GPa

Applications of Molybdenum Crucible

Molybdenum crucible is widely used in sapphire single crystal growth furnace, quartz glass melting furnace, rare earth smelting furnace and other industrial furnace core vessel.

Packaging of Molybdenum Crucible

Standard Packing:

Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 440 gallon liquid totes Special package is available on request.

ATTs’Molybdenum Crucible is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.

Chemical Identifiers

Linear Formula	Mo
CAS	7439-98-7
MDL Number	MFCD00003465
EC No.	231-107-2
Beilstein/Reaxys No.	N/A
Pubchem CID	23932
SMILES	[Mo]
InchI Identifier	InChI=1S/Mo
InchI Key	ZOKXTWBITQBERF-UHFFFAOYSA-N

Product	Product Code	Purity	Size	Contact Us
Molybdenum Crucible	ME-Mo-99%-CR	99%	10-500mm OD x 1-30mm WT x 10-600mm H
Molybdenum Crucible	ME-Mo-99.9%-CR	99.9%	10-500mm OD x 1-30mm WT x 10-600mm H
Molybdenum Crucible	ME-Mo-99.95%-CR	99.95%	10-500mm OD x 1-30mm WT x 10-600mm H
