Product Code : ME-Mo-5N-BR
Molybdenum rod has the characteristics of high melting point, good thermal conductivity and small thermal expansion. At high temperature, it has the characteristics of oxidation resistance, high strength and no deformation during processing.ATT specializes in producing high purity uniform shaped Molybdenum Rod with the highest possible density 99.9+% Ultra High Purity Metallic Rodsand smallest possible average grain sizes.
CAS #: 7439-98-7
Linear Formula: Mo
MDL Number: MFCD00003465
EC No.: 231-107-2
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
| Product | Product Code | Purity | Size | Contact Us |
Molybdenum rod has the characteristics of high melting point, good thermal conductivity and small thermal expansion. At high temperature, it has the characteristics of oxidation resistance, high strength and no deformation during processing.ATT specializes in producing high purity uniform shaped Molybdenum Rod with the highest possible density 99.9+% Ultra High Purity Metallic Rodsand smallest possible average grain sizes.In addition, ATT produces pure molybdenum and lanthanide-doped molybdenum rods, which are designed for use in high-temperature applications where materials with smaller cross-sections retain ductility after recrystallization.
ATT can manufacture molybdenum rods of any length or cut to the length required by the customer.
| Molybdenum Rod Properties | |
| Molecular Weight | 95.94 |
| Appearance | Silvery |
| Melting Point | 2623 °C |
| Boiling Point | 4639 °C |
| Density | 10280 kg/m3 |
| Solubility in H2O | N/A |
| Electrical Resistivity | 5.2 microhm-cm @ 0 °C |
| Electronegativity | 1.9 Paulings |
| Heat of Fusion | 6.6 Cal/gm mole |
| Heat of Vaporization | 128 K-Cal/gm atom at 4612 °C |
| Poisson's Ratio | 0.31 |
| Specific Heat | 0.0599 Cal/g/K @ 25 °C |
| Tensile Strength | N/A |
| Thermal Conductivity | 1.38 W/cm/K @ 298.2 K |
| Thermal Expansion | (25 °C) 4.8 µm·m-1·K-1 |
| Vickers Hardness | 1530 MPa |
| Young's Modulus | 329 GPa |
Synonyms
GF54490574, GF60430766, 10032, 10033, 10034, 11475
| Diameter (inch) | Length (inch) | Diameter Tolerance (inch) | Length Tolerance (inch) |
| 0.08 – 0.40 | <315> | ±0.005 | +0.08, -0 |
| 0.40 – 0.80 | <118> | ±0.010 | +0.08, -0 |
| 0.80 – 4.00 | <78> | ±0.015 | +0.08", -0 |
| >4.00 | <40> | ±0.025 | +0.08, -0 |
In addition, we can also customize according to your requirements.
Applications Of Molybdenum Rod
* Used in steel-making additives, electric vacuum parts, gas pipes, lead-wire, sidebar, daily-use glass, optical glass, insulation material, and glass fiber
* Used to stretch into molybdenum wire and molybdenum electrode
* Hot Zones for high-temperature furnaces.
* Sputtering targets for coating solar cells & flat screens.
* Glass melting electrodes
* Heat shields
* Semiconductor base plates.
* Brazing fixtures & Boring bars
* Tools & Contacts
* Pigments and catalysts.
* Filaments, ribbons, and wires for lighting
Excellent Strength & Stiffness at high temperatures.
High purity and excellent creep resistance.
Good machinability and easily fabricated.
High dimensional stability and excellent corrosion resistance
Low emissivity and vapor pressure.
Good electrical conductivity and low thermal expansion
Ductile and corrosion resistant.
Excellent Thermal conductivity.
Standard Packing:
Sealed bags in carton boxes. Special package is available on request.
ATTs’ Molybdenum Rod is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.
Chemical Identifiers
| Linear Formula | Mo |
| CAS | 7439-98-7 |
| MDL Number | MFCD00003465 |
| EC No. | 231-107-2 |
| Beilstein/Reaxys No. | N/A |
| Pubchem CID | 23932 |
| SMILES | [Mo] |
| InchI Identifier | InChI=1S/Mo |
| InchI Key | ZOKXTWBITQBERF-UHFFFAOYSA-N |
