Product Code : NM-Al-NN-PO
Aluminum (Al) Nanoparticles, nanodots or nanopowder are black spherical high surface area metal particles. Nanoscale Aluminum Particles are typically 10-30 nanometers (nm) with specific surface area (SSA) in the 30 - 70 m2/g range and also available with an average particle size of 70 -100 nm range with a specific surface area of approximately 5 - 10 m2/g. Nano Aluminum Particles are also available in passivated and in ultra high purity and high purity, carbon-coated, and dispersed forms. They are also available as a dispersion through the AE Nanofluid production group. Nanofluids are generally defined as suspended nanoparticles in solution either using surfactant or surface charge technology. Nanofluid dispersion and coating selection technical guidance is also available. Other nanostructures include nanorods, nanowhiskers, nanohorns, nanopyramids and other nanocomposites. Surface functionalized nanoparticles allow for the particles to be preferentially adsorbed at the surface interface using chemically bound polymers.
ATT is a professional supplier of high-purity Aluminum Nanopowder The purity can be 99.99%(4N), 99.995%(4N5), 99.999%(5N).
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
| Product | Product Code | Purity | Size | Contact Us |
Product Information
Aluminum (Al) Nanoparticles, nanodots or nanopowder are black spherical high surface area metal particles. Nanoscale Aluminum Particles are typically 10-30 nanometers (nm) with specific surface area (SSA) in the 30 - 70 m2/g range and also available with an average particle size of 70 -100 nm range with a specific surface area of approximately 5 - 10 m2/g. Nano Aluminum Particles are also available in passivated and in ultra high purity and high purity, carbon-coated, and dispersed forms. They are also available as a dispersion through the AE Nanofluid production group. Nanofluids are generally defined as suspended nanoparticles in solution either using surfactant or surface charge technology. Nanofluid dispersion and coating selection technical guidance is also available. Other nanostructures include nanorods, nanowhiskers, nanohorns, nanopyramids and other nanocomposites. Surface functionalized nanoparticles allow for the particles to be preferentially adsorbed at the surface interface using chemically bound polymers.
ATT is a professional supplier of high-purity Aluminum Nanopowder The purity can be 99.99%(4N), 99.995%(4N5), 99.999%(5N).
Synonyms
Aluminium nanopowder, nanoaluminum
Aluminum Nanopowder Specification
Size：customized，Nanoscale Aluminum Particles are typically 10-30 nanometers (nm) with specific surface area (SSA) in the 30 - 70 m2/g range and also available with an average particle size of 70 -100 nm range with a specific surface area of approximately 5 - 10 m2/g.
Purity:2N(99%), 3N5(99.95%), 4N(99.99%), 4N5(99.995%),5N(99.999%)，
Per your request or drawing
We can customized as required
Properties（Theoretical）
| Molecular Weight | 26.98 |
| Appearance | Grey |
| Color | black |
| Melting Point | 660.37 °C |
| Boiling Point | 2467 °C |
| Density | N/A |
| Bulk Density | 0.08-0.22 g/m3 |
| True Density | 2700 g/cm3 |
| Size Range | 2-50 nm |
| Average Particle Size | ~ 18 nm (0-50nm) |
| Specific Surface Area | 40-60 m2/g |
| Morphology | Spherical |
| Crystal Phase / Structure | N/A |
| Poisson's Ratio | 0.35 |
| Thermal Expansion | (25 °C) 23.1 µm·m-1·K-1 |
| Vickers Hardness | 167 MPa |
| Young's Modulus | 70 GPa |
| Crystal Structure | cubic |
Chemical composition
Purity：4N5（99.995%）
| Elemental Analysis | Value |
| Al | ≥99.995 |
| Si | ≤0.01 |
| Fe | 0.01 |
| Cu | 0.03 |
| Mg | ≤0.01 |
| Mn | ≤0.01 |
| Pb | ≤0.01 |
| Ni | ≤0.01 |
| Zn | ≤0.01 |
We can customized as required
Chemical composition
Purity：3N（99.995%）
| Elemental Analysis | Value—ppm |
| Al | ≥99.9 |
| Si | ≤65 |
| Fe | ≤110 |
| Mg | ≤25 |
| Mn | ≤10 |
| Cr | ≤5 |
| Cu | ≤280 |
| Ti | ≤7 |
| Ca | ≤5 |
| Zn | ≤10 |
| Sn | ≤5 |
| Ni | ≤34 |
| Pb | ≤12 |
| V | ≤5 |
We can customized as required
Applications of Aluminum Nanopowder
Aluminum nanopowder can be used in catalysis applications as well as biomedical research. It can be added to heat transfer fluids, composite materials, package materials, transparent conductive fluids and wear resistant parts in order to strengthen their properties.
Packing of Aluminum Nanopowder
Standard Packing:
Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 440 gallon liquid totes Special package is available on request.
ATTs’ Aluminum Nanopowder is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.
Aluminum nanoparticles are highly reactive and flammable, therefore it should be handled with care and rapid moves, vibrations should be avoided. Nanopowder should be kept away from sunlight, any kind of heating, moisture and impacts. Coagulation of the particles is a serious problem, so, nanopowder should be sealed under vacuum and should be kept in cool and dry conditions. Air contact should be avoided.
Chemical Identifiers
| Linear Formula | Al |
| CAS | 7429-90-5 |
| MDL Number | MFCD00134029 |
| EC No. | 231-072-3 |
| Beilstein/Reaxys No. | N/A |
| Pubchem CID | 5359268 |
| IUPAC Name | aluminum |
| SMILES | [Al] |
| InchI Identifier | InChI=1S/Al |
| InchI Key | XAGFODPZIPBFFR-UHFFFAOYSA-N |
