Product Code : ME-Ru-5N-CB
Ruthenium is a rare member of the platinum group of metals (abundance 0.001 ppm in the earth's crust). Ruthenium is a polyvalent hard white metal and a member of the platinum group, together with rhodium, palladium, osmium, iridium and platinum. It is a lustrous, silvery colored metal which is unaffected by air, water and acids, but is soluble in fused alkalis. Extraction of the metal is achieved by several techniques; for example, extraction of the mixed platinum group metals by dissolution in aqua regia, followed by treatment of the various soluble and insoluble fractions.
ATT specializes in producing high purity Ruthenium Metal Cubes in a range of standard and custom dimensions. ATT produces to many standard grades when applicable, including Mil Spec (military grade); ACS, Reagent and Technical Grade; Food, Agricultural and Pharmaceutical Grade; Optical Grade, USP and EP/BP (European Pharmacopoeia/British Pharmacopoeia) and follows applicable ASTM testing standards. Typical and custom packaging is available. Please request a quote above to receive pricing information based on your specifications.
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
| Product | Product Code | Purity | Size | Contact Us |
Product Information
Ruthenium is a rare member of the platinum group of metals (abundance 0.001 ppm in the earth's crust). Ruthenium is a polyvalent hard white metal and a member of the platinum group, together with rhodium, palladium, osmium, iridium and platinum. It is a lustrous, silvery colored metal which is unaffected by air, water and acids, but is soluble in fused alkalis. Extraction of the metal is achieved by several techniques; for example, extraction of the mixed platinum group metals by dissolution in aqua regia, followed by treatment of the various soluble and insoluble fractions.
ATT specializes in producing high purity Ruthenium Metal Cubes in a range of standard and custom dimensions. ATT produces to many standard grades when applicable, including Mil Spec (military grade); ACS, Reagent and Technical Grade; Food, Agricultural and Pharmaceutical Grade; Optical Grade, USP and EP/BP (European Pharmacopoeia/British Pharmacopoeia) and follows applicable ASTM testing standards. Typical and custom packaging is available. Please request a quote above to receive pricing information based on your specifications.
Synonyms
Ruthenium Cubes Specification
Size：customized
Purity:2N(99%), 3N(99.9%), 4N(99.99%), 5N(99.999%).
Per your request or drawing
We can customized as required
Properties（Theoretical）
| Molecular Weight | 101.07 |
| Appearance | solid cubes |
| Melting Point | 2334 °C |
| Boiling Point | 4150 °C |
| Density | 12370 kg/m3 |
| Solubility in H2O | N/A |
| Electrical Resistivity | 7.6 microhm-cm @ 0 °C |
| Electronegativity | 2.2 Paulings |
| Heat of Fusion | 6.1 Cal/gm mole |
| Heat of Vaporization | 148 K-cal/gm atom at 3900 °C |
| Poisson's Ratio | 0.3 |
| Specific Heat | 0.057 Cal/g/K @ 25 °C |
| Tensile Strength | N/A |
| Thermal Conductivity | 1.17 W/cm/K @ 298.2 K |
| Thermal Expansion | (25 °C) 6.4 µm/(m·K) |
| Vickers Hardness | N/A |
| Young's Modulus | 447 GPa |
| Superconductivity critical temperature ( K ) | 0.4900 |
| Temperature coefficient ( K⁻¹ ) | 0.00410 @0-100 |
Chemical composition
Purity：5N（99.999%）
| Element | Value |
| Ca | 30 PPM |
| Fe | 30 PPM |
| Si | 20 PPM |
| Au | 3 PPM |
| Mg | 3 PPM |
| Pb | 3 PPM |
| Pd | 10 PPM |
| Pt | 50 PPM |
| Rh | 50 PPM |
| Ag | <1 PPM |
| Cu | 2 PPM |
| Os | 300 PPM |
| Ir | 50 PPM |
| Cr | 3 PPM |
| Mn | <1 PPM |
We can customized as required
Applications of Ruthenium Cubes
Most is used in the electronics industry for chip resistors and electrical contacts. Ruthenium oxide is used in the chemical industry to coat the anodes of electrochemical cells for chlorine production. Ruthenium is also used in catalysts for ammonia and acetic acid production.
Packing of Ruthenium Cubes
Standard Packing:
Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 440 gallon liquid totes Special package is available on request.
ATTs’Ruthenium Cubes is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.
Chemical Identifiers
| Linear Formula | Ru |
| CAS | 7440-18-8 |
| MDL Number | MFCD00011207 |
| EC No. | 231-127-1 |
| Beilstein/Reaxys No. | N/A |
| Pubchem CID | 23950 |
| SMILES | [Ru] |
| InchI Identifier | InChI=1S/Ru |
| InchI Key | KJTLSVCANCCWHF-UHFFFAOYSA-N |
