Product Code : ME-Ag-5N-TP
Silver is a soft, malleable metal with a characteristic sheen. It has the highest thermal and electrical conductivities of all metals. It is generally found uncombined, or in the sulfide or arsenide ores from which it can be recovered as a cyanide complex which is subsequently reduced to the metal, in aqueous solution, by the use of zinc. The pure metal is stable to water and oxygen but is attacked in air by sulfur bearing compounds to form the characteristic black layer of silver sulfide. It is soluble in sulfuric and nitric acids. Some silver salts are sensitive to light (e.g. AgI, AgCl and AgBr) and are of fundamental importance to photography.
ATT specializes in supplying seamless Silver tubing with a variety of dimensions including round, rectangular, square, and Round Metallic Tubes--Selected Dimensionsoval in numerous standard diameters from 0.02 to 6.0 inches and wall thicknesses from 0.003 to 0.500 inches. Tubing can be further processed to produce rings, washers, sleeves and sheaths. Custom configurations are also available. Materials include most metals including the rare earth metals and other advanced materials. Tubes can also be produced from custom alloys for commercial and research applications and for new proprietary technologies. Other available shapes include bar or plate form, as well as custom machined shapes and through other processes such as nanoparticles and in the form of solutions and organometallics.
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
| Product | Product Code | Purity | Size | Contact Us |
Product Information
Silver is a soft, malleable metal with a characteristic sheen. It has the highest thermal and electrical conductivities of all metals. It is generally found uncombined, or in the sulfide or arsenide ores from which it can be recovered as a cyanide complex which is subsequently reduced to the metal, in aqueous solution, by the use of zinc. The pure metal is stable to water and oxygen but is attacked in air by sulfur bearing compounds to form the characteristic black layer of silver sulfide. It is soluble in sulfuric and nitric acids. Some silver salts are sensitive to light (e.g. AgI, AgCl and AgBr) and are of fundamental importance to photography.
ATT specializes in supplying seamless Silver tubing with a variety of dimensions including round, rectangular, square, and Round Metallic Tubes--Selected Dimensionsoval in numerous standard diameters from 0.02 to 6.0 inches and wall thicknesses from 0.003 to 0.500 inches. Tubing can be further processed to produce rings, washers, sleeves and sheaths. Custom configurations are also available. Materials include most metals including the rare earth metals and other advanced materials. Tubes can also be produced from custom alloys for commercial and research applications and for new proprietary technologies. Other available shapes include bar or plate form, as well as custom machined shapes and through other processes such as nanoparticles and in the form of solutions and organometallics.
Synonyms
Silver Tube Specification
Size：Our standard diameters from 0.02 to 6.0 inches and wall thicknesses from 0.003 to 0.500 inches.
Per your request or drawing
We can customized as required
Properties（Theoretical）
| Molecular Weight | 107.87 |
| Appearance | Silver |
| Melting Point | 961.78 °C |
| Boiling Point | 2162 °C |
| Density | 10490 kg/m3 |
| Solubility in H2O | N/A |
| Electrical Resistivity | 1.586 microhm-cm @ 20 °C |
| Electronegativity | 1.9 Paulings |
| Heat of Fusion | 2.70 Cal/gm mole |
| Heat of Vaporization | 60.7 K-Cal/gm atom at 2212 °C |
| Poisson's Ratio | 0.37 |
| Specific Heat | 0.0566 Cal/g/K @ 25 °C |
| Tensile Strength | N/A |
| Thermal Conductivity | 4.29 W/cm/K @ 298.2 K |
| Thermal Expansion | (25 °C) 18.9 µm·m-1·K-1 |
| Vickers Hardness | 251 MPa |
| Young's Modulus | 83 GPa |
| Temperature coefficient ( K⁻¹ ) | 0.00410 @0-100°C |
| Thermal emf against Pt (cold 0C - hot 100C) ( mV ) | 0.74 |
Chemical composition
Purity：5N（99.999%）
| Element | Value |
| Zn | 5 PPM |
| Fe | 5 PPM |
| Na | 1 PPM |
| Cu | 70 PPM |
| Pb | 1 PPM |
We can customized as required
Applications of Silver Tube
The alloys of silver have many commercial uses. Sterling silver (92.5% silver, with copper or other metals) is used for silverware and jewelry. Silver is used in photography, dental compounds, solder, brazing, electrical contacts, batteries, mirrors, and printed circuits.
Packing of Silver Tube
Standard Packing:
Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 440 gallon liquid totes Special package is available on request.
ATTs’ Silver Tube is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.
Chemical Identifiers
| Linear Formula | Ag |
| CAS | 7440-22-4 |
| MDL Number | MFCD00003397 |
| EC No. | 231-131-3 |
| Beilstein/Reaxys No. | N/A |
| Pubchem CID | 23954 |
| IUPAC Name | silver |
| SMILES | [Ag] |
| InchI Identifier | InChI=1S/Ag |
| InchI Key | BQCADISMDOOEFD-UHFFFAOYSA-N |
