Product Code : ME-W-99.999%-SF
Tungsten foil is a thin slice of tungsten, with a purity greater than 99.9%, a thickness of 0.05~0.5mm, a width of 5~400mm and a length of 50~1500mm. Its surface states include alkali pickling surface, annealing surface and polished surface. The surface states include alkali pickling surface, annealed surface and polished surface. From the perspective of physical and chemical properties, tungsten foil is a kind of silver-gray metal sheet with metallic luster. The melting point is about 3410℃, the boiling point is about 5660 ℃, and the relative density is 19.35g/cm3.
CAS #: 7440-33-7
Linear Formula: W
MDL Number: MFCD00011461
EC No.: 231-143-9
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
Product | Product Code | Purity | Size | Contact Us |
Tungsten Foil & Tungsten Strip | ME-W-99.95%-SF | 99.95% | 0.05-0.5mm T x 5-400mm W x 50-1500mm L | |
Tungsten Foil & Tungsten Strip | ME-W-99.99%-SF | 99.99% | 0.05-0.5mm T x 5-400mm W x 50-1500mm L | |
Tungsten Foil & Tungsten Strip | ME-W-99.995%-SF | 99.995% | 0.05-0.5mm T x 5-400mm W x 50-1500mm L | |
Tungsten Foil & Tungsten Strip | ME-W-99.999%-SF | 99.999% | 0.05-0.5mm T x 5-400mm W x 50-1500mm L |
Product Information
Tungsten foil is a thin slice of tungsten, with a purity greater than 99.95%, a thickness of 0.05~0.3mm, a width of 100~400mm and a length of 400~1500mm. Its surface states include alkali pickling surface, annealing surface and polished surface. Tungsten foil is a thin slice of tungsten with a purity greater than 99.95%, thickness of 0.05-0.5mm, width of 5-400mm and length of 50-1500mm. The surface states include alkali pickling surface, annealed surface and polished surface. From the perspective of physical and chemical properties, tungsten foil is a kind of silver-gray metal sheet with metallic luster. The melting point is about 3410℃, the boiling point is about 5660 ℃, and the relative density is 19.35g/cm3.
It has the characteristics of low vapor pressure, low evaporation rate, low plastic brittleness transition temperature, low resistivity, good chemical stability, creep resistance, heat resistance and toughness. At room temperature and pressure, it will not react with air, water, concentrated hydrochloric acid, sulfuric acid, nitric acid, hydrofluoric acid and aqua regia and other substances, but will dissolve in the mixture of hydrofluoric acid and concentrated nitric acid. In addition, under heating conditions, it will react weakly with concentrated hydrochloric acid, sulfuric acid, nitric acid and other inorganic acids (except hydrofluoric acid).
Synonyms
GF02629571, GF35593555, GF90049574, GF83538490, GF60432207, GF91197748, GF99741741, GF66018999, GF17648589, 267538, 357197, 267546, 357189, 10414, 10415, 10416, 10417, 13980, 13981
Specifications Of Tungsten Foil & Tungsten Strip
Product Name | Thickness (mm) | Width (mm) | Length (mm) | Material | Standard | Purity |
Tungsten Foil | 0.05-0.15 | 5-300 | >50 | Tungsten | ASTM B760 | ≥99.95% |
Tungsten Strip | 0.15-0.5 | 50-400 | Up to 1500 | Tungsten | ASTM B760 | ≥99.95% |
ATT can design and manufacture according to customer's requirements beyond the standard size.
Chemical Composition for Tungsten Foil & Tungsten Strip
Product | Tungsten content | Impurity content | |
Total content | Content per element | ||
W Foil & W Strip | ≥99.95% | ≤0.05% | ≤0.01% |
Tungsten Foil & Tungsten Strip Properties
Molecular Weight | 183.85 |
Appearance | solid |
Melting Point | 3410 °C |
Boiling Point | 5900 °C |
Density | 19.3 g/cm3 |
Solubility in H2O | N/A |
Electrical Resistivity | 5.65 microhm-cm @ 27 °C |
Electronegativity | 1.7 Paulings |
Heat of Fusion | 8.42 Cal/gm mole |
Heat of Vaporization | 185 K-Cal/gm atom at 5660 °C |
Poisson's Ratio | 0.28 |
Specific Heat | 0.0317 Cal/g/K @ 25 °C |
Tensile Strength | 750 MPa |
Thermal Conductivity | 1.73 W/cm/K @ 298.2 K |
Thermal Expansion | (25 °C) 4.5 µm·m-1·K-1 |
Vickers Hardness | 3430 MPa |
Young's Modulus | 411 GPa |
Applications Of Tungsten Foil & Tungsten Strip
*As a heat shield in the thermal field.
*Used to make heating body.
*Used to make tungsten targets.
Packaging Of Tungsten Foil & Tungsten Strip
Standard Packing:
Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 440 gallon liquid totes Special package is available on request.
ATTs’Tungsten Foil & Tungsten Strip is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.
Chemical Identifiers
Linear Formula | W |
CAS | 7440-33-7 |
MDL Number | MFCD00011461 |
EC No. | 231-143-9 |
Beilstein/Reaxys No. | N/A |
Pubchem CID | 23964 |
SMILES | [W] |
InchI Identifier | InChI=1S/W |
InchI Key | WFKWXMTUELFFGS-UHFFFAOYSA-N |
