Tungsten Molybdenum Alloy Ring

Product Code : AL-WMo-Mo18.6%W-RI

Tungsten Molybdenum Alloy Ring has good high-temperature strength, and similar properties to tungsten but smaller specific gravity than tungsten. It can be used as high-temperature components in rockets, missiles, filaments, parts of electronic tubes, and other high-temperature materials under corresponding high-temperature conditions.

ATT is a professional supplier of high-purity Tungsten Molybdenum Alloy Ring. We also produce disc, granules, ingot, pellets, pieces, powder, rod, wire, sputtering target and in numerous other forms and custom shapes. Other shapes are available by request.

Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.

Product Product Code Purity Size Contact Us
Tungsten Molybdenum Alloy Ring AL-WMo-Mo18.6%W-RI Mo18.6%W Customize
Tungsten Molybdenum Alloy Ring AL-WMo-CU-RI Customize Customize

Product Information

Tungsten was used extensively for the filaments of old-style incandescent light bulbs, but these have been phased out in many countries. This is because they are not very energy efficient; they produce much more heat than light.Tungsten has the highest melting point of all metals and is alloyed with other metals to strengthen them. Tungsten and its alloys are used in many high-temperature applications, such as arc-welding electrodes and heating elements in high-temperature furnaces.

Tungsten Molybdenum Alloy Ring has good high-temperature strength, and similar properties to tungsten but smaller specific gravity than tungsten. It can be used as high-temperature components in rockets, missiles, filaments, parts of electronic tubes, and other high-temperature materials under corresponding high-temperature conditions.

ATT is a professional supplier of high-purity Tungsten Molybdenum Alloy Ring. We also produce disc, granules, ingot, pellets, pieces, powder, rod, wire, sputtering target and in numerous other forms and custom shapes. Other shapes are available by request.


Molybdenum Tungsten Alloy Synonyms

MoW, Molybdenum, compd. with tungsten

Tungsten Molybdenum Alloy Ring Specification

Per your request or drawing

We can customized as require


Properties(Theoretical)

Compound FormulaMoW
Molecular Weight279.8
AppearanceMetallic Solid
Melting PointN/A
Boiling PointN/A
DensityN/A
Solubility in H2ON/A
Exact Mass281.856339
Monoisotopic Mass281.856339


Hardness of  Molybdenum Tungsten Alloy

Hardness of Molybdenum Tungsten Alloy
The Content of Alloys /%Vickers   hardness/MPa
20℃427℃871℃1316℃1649℃
100%Mo1764 MPa637 MPa568 MPa206 MPa176 MPa
Mo18.6%W1891 MPa990 MPa813 MPa441 MPa216 MPa
Mo28.9%W1940 MPa1019 MPa853 MPa490 MPa265 MPa
Mo40.1%W2009 MPa1068 MPa951 MPa568 MPa294 MPa
Mo49.1%W2186 MPa1137 MPa980 MPa686 MPa372 MPa
Mo49.7%W2273 MPa----
Mo59.8%W2372 MPa1235 MPa1039 MPa784 MPa412 MPa
Mo70.8%W2587 MPa----
Mo72.2%W2685 MPa1343 MPa1117 MPa892 MPa510 MPa
Mo84.4%W3185 MPa1176 MPa902 MPa853 MPa500 MPa
Mo89.9%W3499 MPa----
Mo90.4%W3538 MPa1156 MPa902 MPa843 MPa472 MPa
Mo97.3%W3587 MPa902 MPa833 MPa764 MPa402 MPa
Mo99.9%W3861 MPa----


Applications of Tungsten Molybdenum Alloy Ring

Tungsten Molybdenum Alloy Ring is used as high-temperature components in rockets, missiles, filaments, parts of electronic tubes, and other high-temperature materials under corresponding high-temperature conditions. It is widely used In the national defense industry, medical equipment, nuclear industry, and other fields.


Packing of Tungsten Molybdenum Alloy Ring

Standard Packing:

Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 440 gallon liquid totes Special package is available on request.

ATTs’Tungsten Molybdenum Alloy Ring is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.

Chemical Identifiers

Linear FormulaMoW
CAS870196-77-3
MDL NumberN/A
EC No.N/A
Beilstein/Reaxys No.N/A
Pubchem CID57450966
IUPAC Namemolybdenum; tungsten
SMILES[Mo].[W]
InchI IdentifierInChI=1S/Mo.W
InchI KeyMGRWKWACZDFZJT-UHFFFAOYSA-N
