Product Information

Tungsten was used extensively for the filaments of old-style incandescent light bulbs, but these have been phased out in many countries. This is because they are not very energy efficient; they produce much more heat than light.Tungsten has the highest melting point of all metals and is alloyed with other metals to strengthen them. Tungsten and its alloys are used in many high-temperature applications, such as arc-welding electrodes and heating elements in high-temperature furnaces.

Tungsten Molybdenum Alloy Rod has good high-temperature strength, and similar properties to tungsten but smaller specific gravity than tungsten. It can be used as high-temperature components in rockets, missiles, filaments, parts of electronic tubes, and other high-temperature materials under corresponding high-temperature conditions.

ATT is a professional supplier of high-purity Tungsten Molybdenum Alloy Rod. We also produce disc, granules, ingot, pellets, pieces, powder, rod, wire, sputtering target and in numerous other forms and custom shapes. Other shapes are available by request.

Molybdenum Tungsten Alloy Synonyms

MoW, Molybdenum, compd. with tungsten

Tungsten Molybdenum Alloy Rod Specification

Per your request or drawing

We can customized as require

Properties（Theoretical）

Compound Formula	MoW
Molecular Weight	279.8
Appearance	Metallic Solid
Melting Point	N/A
Boiling Point	N/A
Density	N/A
Solubility in H2O	N/A
Exact Mass	281.856339
Monoisotopic Mass	281.856339

Hardness of Molybdenum Tungsten Alloy

Hardness of Molybdenum Tungsten Alloy
The Content of Alloys /%	Vickers hardness/MPa
The Content of Alloys /%	20℃	427℃	871℃	1316℃	1649℃
100%Mo	1764 MPa	637 MPa	568 MPa	206 MPa	176 MPa
Mo18.6%W	1891 MPa	990 MPa	813 MPa	441 MPa	216 MPa
Mo28.9%W	1940 MPa	1019 MPa	853 MPa	490 MPa	265 MPa
Mo40.1%W	2009 MPa	1068 MPa	951 MPa	568 MPa	294 MPa
Mo49.1%W	2186 MPa	1137 MPa	980 MPa	686 MPa	372 MPa
Mo49.7%W	2273 MPa	-	-	-	-
Mo59.8%W	2372 MPa	1235 MPa	1039 MPa	784 MPa	412 MPa
Mo70.8%W	2587 MPa	-	-	-	-
Mo72.2%W	2685 MPa	1343 MPa	1117 MPa	892 MPa	510 MPa
Mo84.4%W	3185 MPa	1176 MPa	902 MPa	853 MPa	500 MPa
Mo89.9%W	3499 MPa	-	-	-	-
Mo90.4%W	3538 MPa	1156 MPa	902 MPa	843 MPa	472 MPa
Mo97.3%W	3587 MPa	902 MPa	833 MPa	764 MPa	402 MPa
Mo99.9%W	3861 MPa	-	-	-	-

Applications of Tungsten Molybdenum Alloy Rod

Tungsten Molybdenum Alloy Rod is used as high-temperature components in rockets, missiles, filaments, parts of electronic tubes, and other high-temperature materials under corresponding high-temperature conditions. It is widely used In the national defense industry, medical equipment, nuclear industry, and other fields.

Packing of Tungsten Molybdenum Alloy Rod

Standard Packing:

Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 440 gallon liquid totes Special package is available on request.

ATTs’Tungsten Molybdenum Alloy Rod is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.

Chemical Identifiers

Linear Formula	MoW
CAS	870196-77-3
MDL Number	N/A
EC No.	N/A
Beilstein/Reaxys No.	N/A
Pubchem CID	57450966
IUPAC Name	molybdenum; tungsten
SMILES	[Mo].[W]
InchI Identifier	InChI=1S/Mo.W
InchI Key	MGRWKWACZDFZJT-UHFFFAOYSA-N

Product	Product Code	Purity	Size	Contact Us
Tungsten Molybdenum Alloy Rod	AL-WMo-Mo18.6%W-BR	Mo18.6%W	Customize
Tungsten Molybdenum Alloy Rod	AL-WMo-CU-BR	Customize	Customize
