Home > Products > Metal & Alloys > Tungsten Metals and Alloys > Tungsten Rhenium Alloy

Tungsten Rhenium Alloy

Product Code : AL-WRe-WRe30%-CU

W-Re alloy is an alloy of tungsten and rhenium. One type of the alloy is low rhenium alloy with rhenium under 5%, the other is high rhenium alloy with rhenium of 20% ~ 30%. Rhenium is a rare metal, scarce and expensive.

The phenomenon that rhenium can improve the strength of the tungsten, molybdenum, chromium and plastic is called "rhenium effect". Adding a small amount (3% ~ 5%) of rhenium increases the starting temperature of tungsten recrystallization by 300 ℃ ~ 500 ℃. W - Re and Mo - Re alloy have good high temperature strength and plasticity, they can be processed into targets, plates, wires and rods used in aerospace, aviation high temperature structure (nozzle, thermal protective screen, etc.), elastic components and electronic components.

Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.

Product Product Code Purity Size Contact Us
Tungsten Rhenium AlloyAL-WRe-WRe30%-CUWRe30%Customize
Tungsten Rhenium AlloyAL-WRe-75W25Re-CU75W25ReCustomize
Tungsten Rhenium AlloyAL-WRe-CU-CUCustomizeCustomize

Product Information

W-Re alloy is an alloy of tungsten and rhenium. One type of the alloy is low rhenium alloy with rhenium under 5%, the other is high rhenium alloy with rhenium of 20% ~ 30%. Rhenium is a rare metal, scarce and expensive.

The phenomenon that rhenium can improve the strength of the tungsten, molybdenum, chromium and plastic is called "rhenium effect". Adding a small amount (3% ~ 5%) of rhenium increases the starting temperature of tungsten recrystallization by 300 ℃ ~ 500 ℃. W - Re and Mo - Re alloy have good high temperature strength and plasticity, they can be processed into targets, plates, wires and rods used in aerospace, aviation high temperature structure (nozzle, thermal protective screen, etc.), elastic components and electronic components.


Tungsten Rhenium Alloy Synonyms

75W25Re, 75W-25Re, W-25, W97Re3, ASM W-10

Tungsten Rhenium Alloy Specification

Per your request or drawing

We can customized as required


Tungsten Rhenium Alloy (WRe) Products

MaterialsWRe3%WRe5%,WRe25%WRe26%customized
Plate
Sheet
Strip
Rod
Sputtering Target
Tube

Other: Spherical Tungsten Rhenium Alloy Powder, Tungsten Rhenium alloy crucibles, Tungsten Rhenium alloy nuts, Tungsten Rhenium alloy bolts, Tungsten Rhenium alloy heating elements, and Tungsten Rhenium alloy shielding screens.



Properties(Theoretical)

Compound FormulaWRe
Molecular Weight370.04
AppearanceGray metallic solid in various forms
Melting Point3400 °C
Boiling Point5660 °C
Density19.7 g/cm3
Solubility in H2ON/A
Tensile Strength1310-2100 MPa
Thermal Expansion4.48 x 10-6K-1
Exact Mass370.906684
Monoisotopic Mass370.906684


Applications of Tungsten Rhenium Alloy

- Microwave communication
- Thermocouple
- Furnace
- Joining

- Aerospace industries


Packing of Tungsten Rhenium Alloy

Standard Packing:

Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 440 gallon liquid totes Special package is available on request.

ATTs’Tungsten Rhenium Alloy is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.

Chemical Identifiers

Linear FormulaWRe
CAS12299-18-2
MDL NumberMFCD02091751
EC No.N/A
Beilstein/Reaxys No.N/A
Pubchem CID25252736
IUPAC Namerhenium; tungsten
SMILES[W].[Re]
InchI IdentifierInChI=1S/Re.W
InchI KeyDECCZIUVGMLHKQ-UHFFFAOYSA-N
